ZYNTECH HONGKONG LIMITED Good quality ! Best service ! Working Hard !
8 Years
| Ask Lasest Price | |
| Brand Name : | LG |
| Model Number : | LC320EUD-SDA2 |
| Payment Terms : | T/T, T/T |
| Delivery Time : | 1-3workingdays |
| Price : | Negotiable |
120Hz+120Hz frame 32inch LCD TV PANEL LC320EUD-SDA2 Resolution1920*1080 Brightness 450cd/m²
120Hz+120Hz frame LG IPS 32inch resolution 1600*900 LCD TV PANEL LC320EUD-SDA2
Brightness is 450cd/m²; Whole view angle is89/89/89/89 ;
It is Used for LCD TV SETS; advertising outside etc
| Manufacturer | LG | Model Namel | LC320EUD-SDA2 |
| Screen Size | 32INCH | Screen Type | LCM , a-Si TFT-LCD |
| Pixel Format | 1920*1080(RGB) , WXGA | Response Time | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) ms |
| Active Area(mm) | 698.4 × 392.85 (H×V) | Arrangement | RGB Vertical Stripe |
| Bezel Area(mm) | 705.4 × 400.0 (H×V) | Outline(mm) | 735.4 × 433 (H×V×D) |
| Luminance | 450 cd/m² (Typ.) | Treatment | Antiglare (Haze 10%), Hard coating (3H) |
| Viewing Angle | 89/89/89/89Min.)(CR≥10 | Contrast Ratio | 1600:1 (Typ.) (TM) |
| Good View at | Symmetry | Work Mode | S-IPS, Normally Black, Transmissive |
| Color Depth | 16.7M/1.06B 72% (CIE1931) | Signal Type | LVDS (4 ch, 8/10-bit) , Connector , 92 pins |
| Frame Rate | 120Hz+120Hz | Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C | Backlight | WLED , 50K hours , With LED Driver |
| Used for | TV SETS ,advertising machine | Touch screen | without |
1. Have our own stock ,kinds of panels . Fast reply RFQ immediately .
2. Ship parts from shenzhen or HK .
3. Safe transportation: Fast and safe transportation that ensures safety of your merchandise.
4. Technology advancement: Professional field applicatoin engineers (FAE) act as your exclusive technical consultant.
5. FQA :
PAYMENT : T/T ,Western union
Shipment : DHL ,FEDEX , TNT,UPS ,Sea , Air shipment etc.
Delivery time : 1-3 working days upon payment.
Products can replace free within 10 days after customers Delivered-Signed if it cannot use due to the quality problems, in the precondition of non-artificial damage. We pay for the freight only for the replacement delivery.
The warranty time is 3-12 months. Within Warranty period, products under serviceable,we will offer the repair service for free,customers afford the cost of the parts. Customers afford the freight.
Even if within the warranty period, if the following occurs, the repair service is not available.
1. The malfunction and damaged caused by incorrect use, the unauthorized repairs and alteration.
2. The damage caused by fire, flood, abnormal voltage, other natural disasters and secondary product damage.
3. The product malfunction caused by the fall and transportation failures after purchase.
4. The malfunction and damaged caused by the other barriers (man-made factors or external device).
Any problems in the after-sales service, please contact our agents or us directly.
|
|
